Описание
Features:
Certification CE
Anti-fog glass
RCA connectors
High-grade waterproofing: IP68.
High-definition and 170 degree wide viewing angle.
Applicable to variety of vehicles: car, truck, RV, etc.
Snap-in design, easy to install.
Simple and modest design and small size will not draw attention.
This helps to avoid incidents and accidents abrasion well.
TV system: NSTC/ PAL
Horizontal resolution: 420 TV lines
Effective pixels: NTSC: 510 (h) * 492 (v)
Minimum illumination: 0.5 lux
Lens: 13.5mm
Viewing angle: 170 degrees
Sync. System: Internal
S / N ratio:> 48dB
Electronic Shutter: 1/50 to 1/100, 000 seconds, 1/60 to 1/100, 000 seconds
Output video: 1.0vpp, 75ohm
White balance: auto
Power: 12 V dc
Current consumption: 90mA
Operating temperature: -20 to + 70 & acirc; ° C, 95% RH maximum
Storage temperature: -40 to + 100 & acirc; ° C, 95% RH maximum
Water-proof: IP66
The image is reversed: left-right mirror
Installation:
Connect the yellow video output connector to terminal display device.
Black power input connector connects to the power output device.
Parking assistance, reversing camera can help us to look at all the circumstances behind.
Product Specifications:
Original box: yes
Video cable length: 6 m
Power cable length: 1.2 m
Характеристики
- Материал корпуса
- Алюминиевый сплав
- Способ подключения
- Проволока
- Направляющие линии
- Да
- Бренд
- GSPSCN
- Тип сигнализации
- Принадлежности / Задняя часть
- Длина видеокабеля
- 6 М
- Тип материала
- АБС-пластик
- Материал объектива
- Стекло
- Parking Assistance Type
- Rear View Camera
- Display
- LCD
- Item Type
- Parking Assistance
- Number
- FLY-083
